Welded Fence Panel
1. Panel:
The panels are made of wire with diameters ranging from 3.0 mm to 6.0 mm, which ensure a very high stiffness of the fence. The panels up to 2000mm, 2500 mm,3000mm wide and with heights ranging from 630 mm to 2500 mm.
2. Mesh size:
50×100 mm, 50×150 mm, 50×200 mm, 75x100mm,100×100 mm, 100×200 mm ,etc.
3. Standard fence specification:
|
Mesh
|
Wire diameter
|
Surface Treatment
|
Panel Width
|
Folds NOS.
|
Height
|
Post height
|
|
50x200mm,
50x150mm
50x100mm
55x200mm
|
3.0mm,4.0mm
4.5mm, 5.0mm
|
Galvanized and
Electrostatic polyester coated or PVC dip coated
|
2.50m
|
2
|
630mm
|
1200mm
|
|
2
|
830mm
|
1400mm
|
|
2
|
1030mm
|
1500mm
|
|
2
|
1230mm
|
1800mm
|
|
2
|
1430mm
|
2000mm
|
|
2
|
1630mm
|
2200mm
|
|
Mesh
|
Wire diameter
|
Surface Treatment
|
Panel Width
|
Folds NOS.
|
Height
|
Post height
|
|
50x200mm,
50x150mm
50x100mm
55x200mm
|
3.0mm,4.0mm
4.5mm,5.0mm
|
Galvanized and
Electrostaticpolyester coated or PVC coated
|
2.50m
|
4
|
1400mm
|
2000mm
|
|
4
|
1600mm
|
2200mm
|
|
4
|
1800mm
|
2400mm
|
|
4
|
2000mm
|
2600mm
|
|
4
|
2200mm
|
2800mm
|
|
4
|
2400mm
|
3000mm
|
4. Fence post:
1) SHS post: 50x50mm,60x60mm,
2) RHS post: 60x40mm,80x40mm,
3) Round post: 48mm,60mm,75mm.
4) Peach post:50x70mm,60x90mm,70x100mm
5. Fence finish
Hot dipped galvanized
Galvanized and polyester powder spraying coated
Galvanized and powder dipped coated
Standard colours: RAL 6005 green, 9005 black,5010 blue, 3000 red, 9010 white
Other colours: All other RAL colours available.
6. Fence application:
Fencings for factories, warehouses, buildings and public utility facilities, such as schools, sports fields and
sports stadiums, playgrounds, as well as private premises.
7. Fence packing:
1) pallet
2) bulk in container.
