Double Wire Fence
1. Panel:
The double wire panel system is a flat panel, constructed from twin wire 6mm/8 mm diameter horizontal wires either side of a 4mm/5 mm/6mm diameter vertical wire creating a strong rigid fence when fitted to a RHS/SHS post.
The panels up to 2000mm, 2500 mm,3000mm wide and with heights ranging from 630 mm to 2500 mm.
2. Mesh size:
50×100 mm, 50×200 mm, 55x200mm,100×200 mm ,etc.
3. Standard fence specification:
|
Mesh size
|
WIRE THICKNESS
|
Coating
|
Panel
Width
|
Panel Height
|
Post
Height
|
|
50x100 mm
50x200mm
55x200mm
100x200mm
|
1xø5 mm/1x6mm Vertical wire
& 2xø6 mm Horizontal wire
0r
1xø5 mm/1x6mm Vertical wire
& 2xø8 mm Horizontal wire
|
Galvanized and Electrostatic
Polyester Coated
|
2.50 m
|
0.63 m
|
1.10m
|
|
0.83 m
|
1.30m
|
|
1.03 m
|
1.50m
|
|
1.23 m
|
1.70m
|
|
1.43 m
|
1.90m
|
|
1.63 m
|
2.10m
|
|
1.83 m
|
2.40m
|
|
2.03 m
|
2.60m
|
|
2.23 m
|
2.80m
|
|
2.43 m
|
3.00m
|
4. Fence post:
1) SHS post: 50x50mm,60x60mm,
2) RHS post: 60x40mm,80x40mm,
3) Peach post:50x70mm,60x90mm,70x100mm
5. Fence finish
Hot dipped galvanized
Galvanized and polyester powder spraying coated
Standard colours: RAL 6005 green, 9005 black,5010 blue, 3000 red, 9010 white
Other colours: All other RAL colours available.
6. Fence application:
Schools ,Hospitals ,General Industrial
General Commercial ,Prestige ,Utilities ,Housing .
7. Fence packing:
1) pallet
2) bulk in container.
